Features:
12 Volt Variable
Brushless Motor
Discharge: Tangential
Speed controlled by varying input voltage
Only a 3% loss in air performance when used in a vacuum condition
Sealed Vacuum: 10.1 inches
Maximum Air Flow: 17.7 CFM
Operational temperatures using Working Air: 0 to 45 degrees Centigrade
Operational temperatures using Ambient Air Temperatures: 0 to 45 degrees Centigrade
Operational temperatures using Storage Air Temperatures: -40 to 85 degrees Centigrade
2-wire power connection: Red=positive DC, Black=negative DC
Compact Design 3" and 5" Diameter
Max. Pressure to 50.0 In. H2O (Sealed)
Max. Air Flows to 45 CFM
Temperature: Working Air: 0°C to +45°C, Ambient Air: 0°C to +45°C, Storage Air: –40°C to +85°C
Dielectric Testing: 500 Volts AC RMS 60 Hz Applied for One Second Between Input Pins and Ground, One Milliamps Leakage Maximum
12 Volt Variable
Brushless Motor
Discharge: Tangential
Speed controlled by varying input voltage
Only a 3% loss in air performance when used in a vacuum condition
Sealed Vacuum: 10.1 inches
Maximum Air Flow: 17.7 CFM
Operational temperatures using Working Air: 0 to 45 degrees Centigrade
Operational temperatures using Ambient Air Temperatures: 0 to 45 degrees Centigrade
Operational temperatures using Storage Air Temperatures: -40 to 85 degrees Centigrade
2-wire power connection: Red=positive DC, Black=negative DC
Compact Design 3" and 5" Diameter
Max. Pressure to 50.0 In. H2O (Sealed)
Max. Air Flows to 45 CFM
Temperature: Working Air: 0°C to +45°C, Ambient Air: 0°C to +45°C, Storage Air: –40°C to +85°C
Dielectric Testing: 500 Volts AC RMS 60 Hz Applied for One Second Between Input Pins and Ground, One Milliamps Leakage Maximum
