Fits Proteam Supercoach if it uses the Ametek Motor 101719 and Proteam Motor 105162. Uses-33326-1 Carbon brushes shown in related items.
Fits the ProTeam Coach Vac, Super Coach, Super Quarter Vac, and Everest Backpack vacuums.
ProTeam SCVH Super CoachVac 10 qt. Backpack Vacuum
ProTeam Super CoachVac HEPA
ProTeam CoachVac 10 Qt. Backpack Vacuum
ProTeam MV MegaVac 10 qt. Backpack Vacuum
ProTeam SQVH Super QuarterVac 6 qt. Backpack Vacuum
ProTeam Super QuarterVac HEPA
Also fits the Mega-Aggressor, Mega-Provac, and Mega-PV100
Also fits the Trail Blazer XP-CPT101
Replaces the following part numbers and others as well: 119347-00, 119347-01, 105162, 101709
NEW PART NUMBER FOR THIS MOTOR IS 122341-07
Fits the ProTeam Coach Vac, Super Coach, Super Quarter Vac, and Everest Backpack vacuums.
ProTeam SCVH Super CoachVac 10 qt. Backpack Vacuum
ProTeam Super CoachVac HEPA
ProTeam CoachVac 10 Qt. Backpack Vacuum
ProTeam MV MegaVac 10 qt. Backpack Vacuum
ProTeam SQVH Super QuarterVac 6 qt. Backpack Vacuum
ProTeam Super QuarterVac HEPA
Also fits the Mega-Aggressor, Mega-Provac, and Mega-PV100
Also fits the Trail Blazer XP-CPT101
Replaces the following part numbers and others as well: 119347-00, 119347-01, 105162, 101709
NEW PART NUMBER FOR THIS MOTOR IS 122341-07
Technical Specs
- Item Vacuum Motor
- Motor/Blower Type Thru-Flow
- Discharge Thru-Flow
- Blower Stages 1
- No. of Speeds 1
- Motor Enclosure Design Open
- CFM @ 2-In. Orifice 147.0
- Vacuum (H2O Sealed) 98.0
- Voltage 120
- Hz 60/50
- Phase 1
- Max. Amps 12.0
- Max. Air Watts 500
- Motor Mounting Type Lug
- Motor Design Universal AC/DC
- Motor Mounting Position All Angle
- Motor Thermal Protection None
- Ins. Class A
- Bearings Ball
- Ambient Temperature 40 Degrees C
- Body Dia. 5.7"
- Overall Height 4-3/4"
- Mounting Brackets Aluminum
- Duty Intermittent
- Average Life 500 hr.
- Motor Efficiency Group Energy Efficient
- Standards UL Listed (E47185), CSA Certified (LR31393)
- Replacement Brushes 2UV81
Customer Questions & Answers
Q: I have an old SuperCoach. Is this motor a replaceable option for 4963447 Domel Model 496.3.447 1-stage 120 volt 5.7 inch Thru Flow tapered vacuummotor
A: Yes
answered on 2018-07-10 00:37:29
answered on 2018-07-10 00:37:29
